15AM-D series thermal overload relay is able to detect both temperature and current. The most distinctive part of this circuit protection device is that it can be equipped with bimetal strips of different resistivity to achieve different opening time. It has found wide applications in the overload and power protection system of motor, electrical ballast, transformer, automobile motor, universal motor, integrated circuit, and other electrical equipment.

Wires: AWG 22#-18# tinned copper wire; the wire model, length, and length of wire stripping is customizable;
Housing: steel sheet with Zinc Nickel plating treatment;
Wire casings: polyester insulating sleeve

Main Features
1. Rated contact capacity, resistive load: 13A/250VAC; inductive load: 5A/250VAC, ψ=0.6-0.7
2. Service life under rated contact capacity: 15,000 times
3. Opening temperature: 60～170℃, in increment of 5℃; tolerance of opening temperature: ±5℃
4. We will choose bimetal strips with different resistivity to meet the opening time clients have required
5. The tensile strength of lead wire should be larger than 50N; and the riveting part won't get loosen easily
6. The contact resistance of thermal switch is no more than 50mΩ

Open and Close Temperature SUPPORT (15AM-D series thermal overload relay)
XXX X
